Mogami 23AWG Guitar Cable - Bulk (W2319)
Mogami 23AWG Guitar Cable - Bulk (W2319)
Regular price
$0.75 USD
Regular price
Sale price
$0.75 USD
Unit price
/
per
Shipping calculated at checkout.
In stock
Couldn't load pickup availability
Most musical instrument sound pick-ups, for example those in electric guitars, are comprised of high impedance circuits driven mainly by voltage, with very little electrical current flow. That is why handling noise (microphonics) can be a problem for guitar cables. Microphonic noise is caused by the minute voltage generated when a cable is flexed, stepped on, etc. Guitar cables must be designed to prevent this, so a conductive PVC layer is placed under the shield conductor to drain away this voltage. Note: This conductive layer must be stripped back when wiring, or a partial short will result.
Configuration | ![]() |
||
Part No. | W2319 | ||
Conductor | Details | 12/0.18TA | |
Size(mm²) | 0.305mm² (#23AWG) | ||
Insulation | Ov. Dia.(mm) | 1.6Ø (0.063") | |
Material | PE | ||
Color | Clear | ||
Sub-Shield | Ov. Dia.(mm) | 1.8Ø (0.071") | |
Material | Conductive PVC (Carbon PVC) | ||
Color | Black | ||
Main-Shield | Served-Shield | Approx. 38/0.16TA | |
Jacket | Ov. Dia.(mm) | 5.0Ø (0.197") | |
Material | PVC | ||
Color | Black | ||
Roll Sizes | 100m (328Ft) | ||
Weight per 100m (328Ft) roll | 3.5Kg |
Price per foot
SKU:W2319
